P Type Dial Caliper Gauge (Thickness Gauge)

• Measurement Range: 0 – 10 mm
• Least Count: 0.05 mm
• Material: Hardened Stainless Steel for durability and long-lasting performance
• Power Supply: 3V CR1632 Lithium-Ion battery
• Energy Efficiency: Low power consumption with extended battery life
• Auto OFF Function: Powers off automatically after 5 minutes to conserve energy
• MM/INCH Conversion: Easy switching between metric and imperial units
• Hold Option: Locks measurements for convenience during use
• Lightweight Design: Ensures easy handling and user comfort

Experience precision with the YUZUKI® P-Type Dial Caliper Gauge/Thickness Gauge, perfect for accurate thickness and diameter measurements. Designed for engineering, machining, and quality control, it ensures reliable performance with durable construction and ergonomic design. Ideal for workshops and labs, it’s your trusted tool for inspections and calibrations. Visit now to enquire or purchase!

The P Type Dial Caliper Gauge, often referred to as a Thickness Gauge, is a precision measurement tool used primarily for assessing the thickness of various materials. This handheld device features a dial caliper gauge with a spring-loaded plunger that enables quick and accurate thickness readings. By pressing the gauge against a material, users can obtain precise measurements in millimeters or inches, displayed on the dial face. The robust construction ensures durability, making it suitable for heavy-duty use in industrial settings. Portable and compact, it’s convenient for on-site inspections.

Applications

The P Type Dial Caliper Gauge is widely used across multiple industries, including metalworking, manufacturing, automotive, and quality control. It’s ideal for measuring the thickness of thin sheets, rubber, paper, plastic, textiles, and other flat materials.

Advantages

1. Precision Measurement: Offers highly accurate thickness measurements, which are essential in quality control and manufacturing.
2. Easy to Use: Compact and ergonomically designed, enabling quick and simple one-handed operation.
3. Versatile: Suitable for a variety of materials, providing flexibility across multiple applications.
4. Durability: Made from high-quality materials, ensuring long-term use even in industrial environments.

This gauge is an essential tool for professionals requiring reliable and consistent thickness measurements, enhancing productivity and ensuring adherence to stringent quality standards.

Here’s a step-by-step guide on how to use a P Type Dial Caliper Gauge (Thickness Gauge) effectively:

How to Use the P Type Dial Caliper Gauge (Thickness Gauge)

1. Prepare the Gauge
   Ensure the gauge is clean and calibrated before each use. Check the dial’s zero setting to confirm accuracy. If needed, adjust the zero using the dial’s calibration knob.
2. Hold the Gauge Properly
   Hold the gauge by its frame, allowing for comfortable and steady control. Place your thumb and fingers on either side of the gauge to ensure balance.
3. Position the Gauge on the Material
   Press the spring-loaded plunger gently against the surface of the material you wish to measure. The gauge is designed to measure the thickness accurately without applying excessive force.
4. Read the Measurement
   Observe the dial to read the thickness measurement. The pointer will display the thickness in either millimeters or inches, depending on your model.
5. Record the Reading
   Once the measurement is displayed, note the thickness reading and lift the gauge gently from the material. Repeat if necessary to confirm accuracy.
6. Reset the Gauge
   After completing the measurements, reset the dial to zero if required, and store the gauge safely to avoid damage.

Tips for Accurate Measurements

• Always measure on a flat surface for best results.
• Avoid excessive force to maintain accuracy.
• Periodically calibrate the gauge to ensure precise readings.
